ATTENTION
DON’T FORGET TO WRITE THE CONFIGURATION IN THE STARTUP
CONFIGURATION WITH THE FOLLOWING COMMANDS:
2 <>
Go to Fault and maintenance management (FMM)
<APPLY ALL> <>
Apply all configurations (written in the running config.)
<CONFIRM> <>
Confirm all configurations (written in the startup config.)
7.1.3 Checking of Correct Working
The Noise Margin (NM) provides qualitative performance information of a specific SHDSL link
according the ITU-T Rec. G.991.2. Perform the next commands to check the status of the unit.
Type following commands
Description
2 <>
Go to Fault and maintenance management (FMM)
<STATUS> <>
Displays the actual system status
CP_01_FMM>STATUS
----------------------------------------------------------------------------
Status : DSL1 DSL2 DSL3 DSL4
----------------------------------------------------------------------------
I/F mode : CO CO CO CO
SYNC : 1 1 1 1
SEGD : 1 1 1 1
Power backoff : 0.0 0.0 0.0 0.0 dbm
Far end power backoff : 0.0 0.0 0.0 0.0 dbm
Loop attenuation : 14.0 14.0 14.0 14.0 dB
NMR : 7.0 7.0 8.0 7.0 dB
Bitrate : 5704 5704 5704 5704 kbit/s
SRU # : 0 0 0 0
Active sync. source : Internal Internal Internal Internal
Remote power state : OFF OFF OFF OFF
----------------------------------------------------------------------------
Temperature : 39.750 C
----------------------------------------------------------------------------
CP_01_FMM>
ATTENTION
THE RECOMMENDED NM VALUE FOR A STABLE SHDSL CONNECTION
IS > 6DB. AFTER INSTALLATION AND ANY CHANGE OF THE
CONFIGURATION THIS VALUE SHOULD BE CHECKED.
7.1.4 Problem with Orion3 Device
In case you have any trouble with the Orion3 device, please send following details to your
FlexDSL contact:
• Application Description
• Main Menu Picture of every device
• Configuration of every device (Please perform with the <DUMP> command
