Extended rates
Extended DSL feature ON/OFF
Line coding
Type of the line encoding (PAM128, PAM64, PAM32, PAM16, PAM8, PAM4)
Baserate
Data Transmission Rate on SHDSL line (BR*64kbit/s). Auto – adaptation mode
Annex
Transmission Mode (ANNEX A, ANNEX B, ANNEX AB)
Payload
Data Transmission interfaces: list of E1 (Nx64) and/or WAN streams
Clock source
Priority list of clock sources
Reserve
The reservation group to which the DSL channel belongs
GS compatible
Enables the Globespan (Conexant) compatibility
Group of E1 parameters
G.704 framing
Framing mode
CRC4
CRC4 mode
AIS Detection
AIS detection mode
AIS Generation
AIS generation mode
E1 clock
Clock source
TS into DSL
List of E1 time slots transmitted/received over DSL
TS for WAN
List of E1 time slots used for WAN data (Ethernet over E1)
Group of Nx64 parameters
EXTRATE
Data Transmission Rate on Nx64 interface (ER*64 kbit/s)
AUTOLOOP
V.54 loop mode
EXTCLOCK
Nx64 clocking mode
Group of RS232 parameters
EXTRATE
Data Transmission Rate on RS232 interface (kbit/s)
Table 4.4 All possible configurations of independent channels
The main operation modes of any device are:
• Independent channels (CO, СP, CX)
• Independent channels with reservation (CO, СP, CX)
• Multipair mode (CO, СP, CX)
• Two-pair mode with reservation (available only in the four-channel version) (CO, СP, CX)
The CONFIG table for the mode with independent channels is presented above. Typical
configurations for other modes are presented below.
Presentation of CONFIG table in “independent channels with reservation” mode. In this
configuration, channels 1, 2, 3 are combined for reservation (CO, CP, CX).
CO_09_CM>CONFIG
--------------------------------------------------------------------------
Running Line Configuration
--------------------------------------------------------------------------
SHDSL DSL1 DSL2 DSL3 DSL4
Mode : Slave(HTU-R) Slave(HTU-R) Slave(HTU-R) Slave(HTU-R)
Extended rates: OFF OFF OFF OFF
Line coding : AUTO AUTO AUTO AUTO
Baserate : AUTO AUTO AUTO AUTO
Annex : A/B A/B A/B A/B
Payload : E1-1,WAN E1-2,WAN E1-3,WAN E1-4,WAN
Clock source : E1-1,Int E1-2,Int E1-3,Int E1-4,Int
Reserve : {=========== Reserve group A ===========} ---
Power : OFF OFF OFF OFF
GS compatible : OFF
E1 E1-1 E1-2 E1-3 E1-4
G.704 framing : OFF OFF OFF OFF
CRC4 : N/A N/A N/A N/A
AIS Detection : ON ON ON ON
AIS Generation: ON ON ON ON
E1 clock : DSL DSL DSL DSL
TS into DSL : 0-31 0-31 0-31 0-31
TS into WAN : NONE NONE NONE NONE
--------------------------------------------------------------------------------
