User Manual LTU Orion 3
20
Table 3.6 Examples of reservation with two channels
The following pictures illustrate the last example in the previous table with reservation of two
channels (The <RESERVE> command is used to configure reservation).
DSL-2: Baserate 61
8 TS WAN
8 TS WAN
28 TS E1-2
1 TS WAN
Total
E1-1, E1-2
69 TS WAN
E1-1, E1-2
8 TS WAN
E1-1, 28 TS E-12
1 TS WAN
DSL-1: Baserate 72
DSL-2: Baserate 61
72 TS WAN
E1-1
29 TS WAN
72 TS WAN
Failure
Failure
61 TS WAN
Total
E1-1
101 TS WAN
72 TS WAN
61 TS WAN
DSL-1: Baserate 89
DSL-2: Baserate 89
E1-1
57 TS WAN
E1-2, E1-3
25 TS WAN
E1-1
57 TS WAN
Failure
Failure
E1-1
57 TS WAN
Total
E1-1, E1-2, E1-3
82 TS WAN
E1-1
57 TS WAN
E1-1
57 TS WAN
