Figure 4.1 Operations of the configuration parameters after the restart
Configuration changes, which are used instantly, are written into the running, startup and new
configuration, and the device continues working according to these configurations.
Figure 4.2 Operations of the configuration parameters with the instant application
Changes in configurations, which are part of a group of configurations that require a confirmation,
are initially written into the new configuration. After the administrator confirms changes in the
group of configurations, this group is copied from the new configuration into the running
configuration and the device starts working according to these configurations. The administrator
also can confirm changes in all groups. After the received running configuration is checked, the
administrator can confirm this configuration. In this case, changes in all groups are copied from
the running configuration into the startup configuration.
