5.3-4 Section 5: 9500B Procedure Mode - Access Guide
Final Width = 215mm
Descriptions assume 9500B/1100
When the 'Select PROCEDURE' screen is
opened, the 9500B will have already
downloaded all the procedures for the selected
model from the Procedure card memory into
internal RAM. The 9500B displays a list of
these on the screen for the user to choose:
1 Year Verification
The 9500B provides the correct outputs for
each of the Manufacturer's recommended test
points used to verify the full performance of
the subject UUT model. Users can slew the
output to determine the UUT error. 'Style 1'
printed results will list these errors. The
procedure is described in sub-section 5.5.
ISO9000 Verify
This is a variant of 1 Year Verification, different
in that the 9500B provides a wider range of test
points to verify performance in greater detail
than is recommended by the Manufacturer.
Verify Pass/Fail
The 9500B provides the correct outputs at each
of the test points, for the user to check whether
the UUT verifies within its specification. Pass/
Fail only is printed on the report. The procedure
is described in sub-section 5.6.
ISO9000 Pass/Fail
This is a variant of Verify Pass/Fail, different
in that the 9500B provides a wider range of test
points to check the specification in greater
detail than is recommended by the
Manufacturer.
To Select a Procedure
Use the
cursor keys, or the spinwheel
to highlight the required procedure, then press
'OK'. The 9500B will transfer to the appropriate
menu screen. Refer to the procedure
description.
ABORT returns to the 'Select USER NAME
...' screen.
Refer to paras 5.3.3 13, Fig 5.3.2.
5.3.3.9 Procedures — Card-Based
Operating Instructions
Selection of UUT Model
When the model of UUT has been chosen from
the menu (derived from the procedure card),
all procedures for the selected model are
automatically downloaded into the 9500B's
internal memory, and the selected procedure
no longer requires the card, as it will be
programmed from the internal memory. Once
the procedure has progressed this far, the
procedure card can be removed and used to
program other Model 9500B units.
Procedure Activation
Once the type of procedure has been selected,
the downloaded user-interactive program will
be run by the 9500B. Subsequent instructions
appearing on the screen will be derived from
the programmed sequences.
Single-Channel Variants - Procedures
This description assumes that the variant
9500B/1100 is being used.
Conclusion
No further routine instructions are given here,
as they may vary from model to model and are
developed within the programmed sequences.
However, the 9500B is programmed also to
interrupt procedures and communicate with
the user when certain events occur. Among
these, the two most important are those of
'Abort' and 'End'.
Types of Procedure
(Procedure Cards supplied from the Procedure
Library)
Variants of three basic procedures (Adjustment
Only, 1 Year Verification and Verify Pass/
Fail) can be found in the Procedure cards
available in the manufacturer's UUT
Calibration Procedure Library (sub-section
1.4).
Adjustment Only
The procedure will cause the 9500B to provide
the correct outputs for each of the
Manufacturer's recommended test points for
adjustment of the subject UUT model. The
identity of adjustment controls, target values
and limits are presented on the screen for the
convenience of the user, who will also decide
whether the adjustment was successful, and
record pass/fail status. The procedure is
described in sub-section 5.4.
5.3.3.8 Select the Procedure for
the Subject UUT Model
TODAY'S DATE TIME
OK
Select PROCEDURE using cursor keys.
Confirm with OK.
Adjustment Only
1 Year Verification
ISO9000 Verify
Verify Pass/Fail
ISO9000 Pass/Fail
ABORT
