8-A4 Appendix A to Section 8: 9500B Maintenance — Error Reporting Subsystem
Final Width = 215mm
ALWAYS: record the total message content for possible use by the Service Center.
8.A.2.2.8 Device-Dependent Errors Reported only Remotely via the IEEE-488 Interface
The error list for remote operations, which are not reported on the front panel screen, is given below:
General
1001, “Active head removed with output on”
1002, “Softkey label too long”
1003, “Confirm with ON”
1004, “Unknown keycode”
1006, “CH1 head control update failure”
1007, “CH2 head control update failure”
1008, “CH3 head control update failure”
1009, “CH4 head control update failure”
1010, “CH5 head control update failure”
1011, “Loss of external reference frequency lock”
1012, “Load <50Ω detected, output off to avoid damage”
1013, “Internal frequency lock has been performed”
1014, “Load mismatch detected: UUT <50kΩ”
1015, “Load mismatch detected: UUT >150Ω”
1016, “Loss of internal reference frequency lock”
1017, “Trigger cable deselected with output on”
1018, “No head present on channel 1”
1019, “No head present on channel 2”
1020, “No head present on channel 3”
1021, “No head present on channel 4”
1022, “No head present on channel 5”
1023, “Active signal cable removed with output on”
1024, “Head interrupt - OFF timeout”
1025, “Zero Skew requires at least two heads”
1026, “Output must be ON”
1027, “Alignment must be adjusted before deselecting default”
1028, "Head on channel 1 has not been recognised"
1029, "Head on channel 2 has not been recognised"
1030, "Head on channel 3 has not been recognised"
1031, "Head on channel 4 has not been recognised"
1032, "Head on channel 5 has not been recognised"
1033, "9520 head or better required for 150ps edge"
1034, "9530 head required for sine greater than 1.1GHz"
1035, "Command not available for single channel configuration"
1036, "Base unit cannot calibrate at required frequency"
1037, "9550 head required for 25ps edge"
1038, "9550 head can only be used for 25ps edge"
1039, "At least one signal channel must always be selected"
1040, "CH1 Load <50k\352 detected, output off to avoid damage"
1041, "CH2 Load <50k\352 detected, output off to avoid damage"
1042, "CH3 Load <50k\352 detected, output off to avoid damage"
1043, "CH4 Load <50k\352 detected, output off to avoid damage"
1044, "CH5 Load <50k\352 detected, output off to avoid damage"
1045, "CH1 Load mismatch detected: UUT <50k\352"
1046, "CH2 Load mismatch detected: UUT <50k\352"
1047, "CH3 Load mismatch detected: UUT <50k\352"
1048, "CH4 Load mismatch detected: UUT <50k\352"
1049, "CH5 Load mismatch detected: UUT <50k\352"
1050, "CH1 Load mismatch detected: UUT >150\352"
1051, "CH2 Load mismatch detected: UUT >150\352"
1052, "CH3 Load mismatch detected: UUT >150\352"
1053, "CH4 Load mismatch detected: UUT >150\352"
1054, "CH5 Load mismatch detected: UUT >150\352"
1055, "9560 head required for sine greater than 3.2GHz"
1056, "This function is not available from a 9560 head"
1057, "9560 head does not provide 1M\352 in this function"
1058, "9560 cannot source 1M\352 trigger signals"
1059, "9560 requires a 3.2GHz option base"
1060, "Incompatable heads for dual sine mode"
1061, "9560 head required for timing marker < 450ns"
1062, "9560 head required for 70ps edge"
1063, "Calibration of this function not allowed with a 9560"
1064, "Multi-channel DC cannot mix 9560 with other head types"
1065, "Pulse Width characterisation requires 9500B hardware"
5010, “Priority OFF received”
5011, “Gain request limited”
5012, “Failed to read from flash RAM”
5013, “Corrupt VCO correction”
5014, “Failed to save VCO correction”
5015, "Corrupt lf sin dc offset correction"
5016, "Failed to save lf sin dc offset correction"
5017, "Corrupt timing marker zero correction"
5018, "Failed to save timing marker zero correction"
5019, "Corrupt timing marker peak correction"
5020, "Failed to save timing marker peak correction"
5021, "Timing marker peak failed, setting defaults"
5022, "Octal dac value out of range, using default"
5023, "Peak detect not cleared, setting defaults"
5025, "VCO unchrs'd - Using default"
5027, "Frequency Crystal DAC unchrs'd - Using default"
5028, "LF sine DC offset unchrs'd - Using default"
5029, "Triangular TMks unchrs'd - Using default"
5030, "Crystal DAC chrsn corrupt - Using default"
5031, "Square TMk chrsn failed - setting defaults"
5032, "Failed to save Square TMk chrsn failed"
5033, "Square TMk chrsn unchrs'd - Using default"
5034, "Square TMk chrsn corrupt - Using default"
5035, "Pulse Width Failed to characterise"
5036, "Pulse width uncharacterised - Using default"
-300,"Device specific error"
-312,"PUD memory lost"
-315,"Selftest failed"
-330,"Configuration memory lost"
-350,"Queue overflow"
8.A.2.2.9 Device-Dependent Errors Reported both Locally and Remotely
Errors are reported both on the front panel screen and via the IEEE-488 interface. Note that the locally-presented error message
will not include the error number.
