Infratec™ 1241 Grain Analyzer
4:36 Service Manual 1001 5015 / Rev. 4
4.12 Hardware Error Log (xxxxxxxx.HL)
4.12.1 Error Word
Presents the error that was received when the command was executed.
Position in instrument Hardware Error Code in bold:
E.g. "20 - 304/1ef3/201/20/0/0/0/450".
Hardware Errors
0001 Instrument hardware communication error
0002 Detector ADC error
0004 Monochromator grating motor start-up error
0010 MU/TWM data range error
0020 Cell blocked error
0040 More sample required
0080 Path length error
0200 Measuring unit speckle detector error
0400 Drawer out
0800 TWM shutter error
1000 TWM wiper error
2000 TWM not full
4000 TWM loadcell error
Software Errors
8000 Hardware Communication error
8101 Monochromator grating motor error
8102 Save monochromator constant error
8103 Monochromator HW EEPROM error
8104 Detector EEPROM error
8105 Monochromator SW EEPROM error
8203 Max offset error
8204 Min offset error
8205 Number of ADC reads error
8207 Overrun error
820C Reference scan too low
820D Too few valid samples collected
820E Monochromator shutter not moving
8302 TWM
8303 TWM HW EEPROM error
8304 TWM SW EEPROM error
8502 Lamp on/off error
8503 Display on/off error
8504 Backlight on/off error
8505 Contrast on/off error
