Infratec™ 1241 Grain Analyzer
Service Manual 1001 5015 / Rev. 4 5:45
5.3.10 Replacement of Conveyor Motor
Note: The replacement is carried out with the Measuring Unit
standing apart.
1. Disconnect the Conveyor Motor Cable from the Measuring Unit Board.
2. Remove the three screws holding the Conveyor Motor.
3. Exchange the Conveyor Motor and assemble in reverse order.
