Foss Infratec 1241 Service Manual

Infratec™ 1241 Grain Analyzer
4:42 Service Manual 1001 5015 / Rev. 4
4.12.4 Status Word 2
"Sub-error", presents more detailed information about what went wrong when the
error occurred.
Position in instrument Hardware Error Code in bold:
E.g. "20 - 304/1ef3/201/20/0/0/0/450".
Id (hex) Specification Note Source
0001 MU board status 0/1 - old/new MU
0002 MU SW status 0/1 - old/new MU
0004
Monochromator board
status
0/1 - old/new Monoch.
0008
Monochromator SW
status
0/1 - old/new Monoch.
0010 TWM board status 0/1 - old/new TWM
0020 TWM SW status 0/1 - old/new TWM
00C0 Not used - -
0100 STM installed
Sample Transport Module is
installed
STM
0200 EID installed Electronic ID is installed EID
0400 ASTM installed Not used Asterix STM is installed ASTM
7C00 Not used - -
8000 IPMode 0/1 - SP/IP DSP
