Infratec™ 1241 Grain Analyzer
Service Manual 1001 5015 / Rev. 4 4:31
4.11 Error Codes in Software Log (SL) and Hard-
ware Log (HL)
When reviewing the SL and HL log files it's a good idea to look at the two files
simultaneously. Try to compare the entries using the time stamps. This way you will
many times get a better understanding because you can see both what the customer
reported (SL) and what command was sent at the same time. In the HL file you will
also see the status reported back by the module that was addressed.
SL
Error
HL
Error
Message to the User (What
possibly can be done before
contacting Service)
Comments Note
32768 0x8000 Hardware error. See
4.11.7
33025 0×8101 Grating motor error. Monochromator Motor cannot
move.
33026 0×8102 Monochromator EEPROM er-
ror.
The Monochromator was not
able to save constants in its
EEPROM.
33027 0x8103 Monochromator EEPROM er-
ror.
Problems to read/write.
33028 0x8104 Detector EEPROM error.
33029 0x8105 Monochromator EEPROM er-
ror.
Data in PROM outside limits.
33283 0x8203 Offset (darkness) is too high.
Make sure the right hand Door
and the Hopper are closed and
retry analysis.
Max offset error > 2000 bits.
33284 0x8204 Offset (darkness) is too low.
Contact support.
Min offset error < 50 bits in
offset.
33285 0x8205 Number of ADC reads in error
33287 0x8207 Overrun error The detector receives to much
light, it gets oversaturated.
Maybe there is a need for an
aperture, read more in section
5.2.6 and TN 1355.
33289 0x8209 Gain is stepped too far down
(i.e. Tries to go be low gain
1*1).
33291 0x820B Analysis cancelled, Max time
exceeded.
Instrument time out error.
33292 0x820C Reference scan light level is
too low. Check the lamp and
clean the Cell. More informa
-
tion is to be found in User
Manual
Reference scan is below its
limits (<15000 at gain 1*1,
<30000 at gain 1*2).
See
4.11.8
33293 0x820D Too few valid samples collect-
ed.
See
4.11.9
33294 0x820E Monoc shutter error Monochromator shutter cannot
move.
See
4.11.10
