Foss Infratec 1241 - Replacement of Variable Motor

Infratec™ 1241 Grain Analyzer
5:44 Service Manual 1001 5015 / Rev. 4
5.3.9 Replacement of Variable Motor
Note: The replacement is carried out with the Measuring Unit
standing apart.
Replacement is a factory repair.
Fig. 5:45 Nut and screws
Exchange the Variable Cell Motor and assemble in reverse order.
Fig. 5:46
R
S
1
2
V
D
C
1241113
