Infratecâ„¢ 1241 Grain Analyzer
2:18 Service Manual 1001 5015 / Rev. 4
2.2.13 STM (Optional)
The Sample Transport Module is an optional device used for samples that are not fit
to be taken through the Measuring Unit sample cell, e.g. moist samples or even
liquids. Such samples may be green-malt, beer, boiled rice etc. Several different
cuvette models and sizes are available for different kinds of sample types.
The STM consist hardware wise of an Elevator Unit which includes a motor that
drives the sample cuvette down in front of the detector and electronics to
communicate commands to the DSP. The position of the cuvette is detected by two
magnet sensors in the elevator unit.
Electrically the STM is connected to either of the two ports on the measuring Unit.
For installation and usage see the User Manual for Infratec 1241 Modules, p/n
60043623
