Infratec™ 1241 Grain Analyzer
5:52 Service Manual 1001 5015 / Rev. 4
5.4 Test Weight Module
5.4.1 Replacement of Test Weight Balance Complete
Test Weight Control Kit P/N 1001 1779
1. Disconnect the TWM from the Infratec. Use the installation description in User
Manual for Infratec 1241 Modules, p/n 60043623, in the reverse order. Unfortu
-
nately it is necessary to do this due to two constraints;
– it is a Balance and the support should be steady
– the total height of the combined instrument should not exceed the normal
length of an operator when placed on an ordinary laboratory table.
2. Dismantle the Test Weight Balance from the cabinet. Four screws must be re-
moved.
3. Replace the Test Weight Balance and remount the TWM on the Infratec accord-
ing to the installation procedure in the User Manual.
4. Check the Balance from the User Menu, go to Application Model/ Test Weight/
Balance Control. Follow the instructions given on the display. ??
5. Start up the instrument and let it go through the Startup Test.
6. Perform a TWM balance calibration, see 5.7.2 TWM Balance Calibration on
page 5:74.
