100
Process parame-
ters for spot weld-
ing
SPt
Spot welding time
0.1 - 10.0 s
Factory setting: 1.0 s
Process parame-
ters for monitor-
ing and
components
The following process parameters can be set and displayed for the system components of
a welding system:
C-C
Cooling unit mode
To determine whether a cooling unit is to be switched on or off, or operated automatically
Setting range: eco / auto / on / off (depending on the cooling unit)
Factory setting: auto
C-t
Delay time flow sensor
For setting the time from when the flow sensor responds until a warning message is output
Setting range: 5 - 25 s
Factory setting: 10 s
CFU
Cooler flow warning limit
Setting range: off, 0.75 - 0.95 l/min
Factory setting: off
Fdi
Feeder inching speed
in m/min (ipm)
For setting the wire speed at which the wire electrode is threaded into the torch hosepack
Setting range:
min. - max. (depending on the wirefeeder)
Factory setting: 10.0 m/min
ito
Ignition time-out
Length of wire that is fed before the safety cut-out trips
Setting range: off / 5 - 100 mm (0.2 - 3.94 in.)
Factory setting: off
The ignition time-out process parameter is a safety function. The length of wire that is fed
before the safety cut-out trips may differ from the pre-set wire length, particularly when the
wire is being fed at fast wire speeds.
How it works:
Once the torch trigger is pressed, gas pre-flow begins immediately. Wirefeeding then be-
gins, followed by ignition. If no current starts flowing before the specified length of wire has
been fed, the power source cuts out automatically.
To try again, press the torch trigger again.
