114
IE
Current arc energy in kJ
The arc energy is the sum total of the arc power and calculates the heat input of the weld
seam most recently produced.
If the weld seam length is known the electrical energy input can be calculated:
E = IE / L
E Electrical energy input in kJ/cm
IE Arc energy in kJ
L Length of the weld seam in cm
The arc energy is preferably used during manual welding.
I-M1
Current motor current in A, wirefeeder 1
(wirefeeder next to the arc)
I-M2
Current motor current in A, wirefeeder 2
(e.g. the rear wirefeeder in a push-pull system)
I-M3
Current motor current in A, wirefeeder 3
(e.g. an unreeling wirefeeder in a push-pull system with unreeling wirefeeder)
CFI
Current flow rate in l/min on the cooling unit
(with built-in OPT/i CU flow temperature sensor option)
Error output if flow rate < 0.7 l/min
CU-t
Current coolant temperature in °C on the cooling unit
(with built-in OPT/i CU flow temperature sensor option)
Error output if coolant temperature > 70 °C
(measured during coolant return)
I-t
Arc time in h
DC-t
Total power source operating hours in h
Gcon
Total gas consumption in l
Setting the interi-
or lighting
Select Setup menu / Settings / System / CLS
Press the right adjusting dial
Select the desired duration by turning the right adjusting dial:
off ... interior lighting switched off
1 - 60 ... interior lighting is switched on for the duration entered
on ... interior lighting is switched on permanently
Press the right adjusting dial
To exit the Setup menu, press the "Welding process" and "Mode" buttons at the same
time
