TIG welding
Safety
WARNING!
Danger from incorrect operation.
Possible serious injury and damage to property.
► Do not use the functions described here until you have read and completely under-
stood these Operating Instructions.
► Do not use the functions described here until you have fully read and understood all of
the Operating Instructions for the system components, in particular the safety rules!
WARNING!
An electric shock can be fatal.
If the power source is connected to the mains electricity supply during installation, there is
a high risk of very serious injury and damage.
► Before carrying out any work on the device make sure that the power source mains
switch is in the "O" position
► Before carrying out any work on the device make sure that the power source is un-
plugged from the mains
Preparations Move the mains switch to the "O" position
Disconnect the mains plug
Remove the MIG/MAG welding torch
Disconnect the grounding (earthing) cable from the (-) current socket
Plug the grounding (earthing) cable into the 2nd (+) current socket and twist to fasten it
Use the other end of the grounding (earthing) cable to establish a connection to the
workpiece
Plug the bayonet current plug on the TIG gas-valve torch into the (-) current socket
and twist it clockwise to fasten it
Screw the pressure regulator onto the (argon) gas cylinder and tighten it
Connect the gas hose of the TIG gas-valve torch to the pressure regulator
Plug in the mains plug
TIG welding
CAUTION!
Risk of injury and damage from electric shock.
As soon as the mains switch is in the "I" position, the tungsten electrode of the welding
torch is live.
► Make sure that the tungsten electrode does not touch any persons or electrically con-
ductive or earthed parts (e.g. housing, etc.)
Move the mains switch to the "I" position
IMPORTANT! For optimum welding results, the manufacturer recommends performing an
R/L alignment when starting the device for the first time and when any changes are made
to the welding system.
