MMA welding
Safety
WARNING!
Danger from incorrect operation.
Possible serious injury and damage to property.
► Do not use the functions described here until you have read and completely under-
stood these Operating Instructions.
► Do not use the functions described here until you have fully read and understood all of
the Operating Instructions for the system components, in particular the safety rules!
WARNING!
An electric shock can be fatal.
If the power source is connected to the mains electricity supply during installation, there is
a high risk of very serious injury and damage.
► Before carrying out any work on the device make sure that the power source mains
switch is in the "O" position
► Before carrying out any work on the device make sure that the power source is un-
plugged from the mains
Preparations Move the mains switch to the "O" position
Disconnect the mains plug
Remove the MIG/MAG welding torch
NOTE!
Check the rod electrode packaging or labelling to determine whether the rod elec-
trodes are for positive pole or negative pole welding.
Plug the grounding (earthing) cable into either the (-) or the (+) current socket depend-
ing on the type of electrode, and twist to fasten it
Use the other end of the grounding (earthing) cable to establish a connection to the
workpiece
Plug the bayonet current plug of the electrode holder cable into the free current socket
with the opposite polarity, according to the type of electrode, and twist it clockwise to
latch it in place
Plug in the mains plug
MMA welding
CAUTION!
Risk of injury and damage from electric shock.
As soon as the mains switch is in the "I" position, the rod electrode in the electrode holder
is live.
► Make sure that the rod electrode does not touch any persons or electrically conductive
or earthed parts (e.g. housing, etc.)
Move the mains switch to the "I" position
