77
EN
Welding voltage
1)
in V
Setting range: depends on the welding process and welding program selected
Before the start of welding, the machine automatically displays a standard value based on
the programmed parameters. The actual value is displayed during welding.
Pulse/dynamic correction
for influencing the short-circuiting dynamic at the instant of droplet transfer
Setting range: -10 - +10
Factory setting: 0
- ... harder and more stable arc
0 ... neutral arc
+ ... soft and low-spatter arc
Special function
any parameter can be assigned to this (see page 41)
The function can be selected if a parameter has been saved.
Welding parame-
ters for MIG/MAG
standard manual
welding
The following welding parameters can be set and displayed for MIG/MAG standard manual
welding:
using the left adjusting dial:
Wire speed
1)
for setting a harder, more stable arc
Setting range: 0.5 - 25 m/min
2)
/ 20 - 980 ipm.
2)
Special function
any parameter can be assigned to this (see page 41)
The function can be selected if a parameter has been saved.
