76
Welding current
1)
in A
Setting range: depends on the welding process and welding program selected
Before the start of welding, the machine automatically displays a standard value based on
the programmed parameters. The actual value is displayed during welding.
Wire speed
1)
for setting a harder, more stable arc
Setting range: 0.5 - 25 m/min
2)
/ 20 - 980 ipm.
2)
Special function
any parameter can be assigned to this (see page 41)
The function can be selected if a parameter has been saved.
Penetration stabilizer
4)
(see page 95)
Setting range: 0 - 10 m/min / 0 - 393.7 ipm
Factory setting: 0
using the right adjusting dial:
Arc length stabilizer
4)
(see page 97)
Setting range: 0 - 2
Factory setting: 0
Arc length correction
for correcting the arc length, which is pre-set by the characteristic or the synergic program
Setting range: -10 - +10
Factory setting: 0
- .... shorter arc length
0 ... neutral arc length
+ ... longer arc length
