84
Press the "Welding process" button until the LED for the STICK/TIG welding process
lights up and "TIG" is shown on the display.
After a short time, the currently set welding current is shown on the display. The welding
current indicator lights up.
The welding voltage is applied to the welding socket with a three second time lag.
NOTE!
Parameters that have been set on a system component control panel (e.g. wire feed
unit or remote control) might not be able to be changed on the power source control
panel.
To change the welding current, turn the left adjusting dial
The altered welding current is applied immediately.
Adjust the process parameters accordingly to make user- or application-specific set-
tings on the welding system
Open the gas stop valve on the TIG gas-valve torch
Set the desired shielding gas flow rate on the pressure regulator
Start welding (ignite the arc)
2
2
3
4
5
6
7
