Fuji Xerox DocuPrint CM505 da Administrator's Guide

Replacing Consumables
63
Maintenance
3
9 Push the drum cartridge straight in the
housing until it stops.
Note • Place the protective cover into the box.
10 Remove the orange protective covering of
the installed drum cartridge and discard it.
11 Return the cover to the original position.
12 Rotate the two lock levers of the inner cover
while pressing the cover with the other hand
to secure the inner cover.
