3 Maintenance
74
Maintenance
3
4 Unlock the two levers on the transfer roller
and lift up the roller to remove it.
5 Grasp the levers located on each sides of
the new transfer roller and align the arrows
on the transfer roller with the arrows inside
the machine.
6 Place the front of the transfer roller to until
the roller clicks into place.
7 Close the right hand cover.
Note • When closing the right hand cover, put
your hand near the handle as shown in
the illustration, and then push the cover
firmly to the machine.
• If the front cover is not completely closed,
a message will appear and the machine
will remain paused.
Replacing Separator Rollers
There are three separator rollers in the machine which need to be replaced periodically.
One is in the tray and the others are inside the machine. All the separator rollers are
replaced in the same way as described in this section.
