Fuji Xerox DocuPrint CM505 da Administrator's Guide

Cleaning the Machine
83
Maintenance
3
10 Hold and lift up the top handles of the
transfer belt unit.
Note • Do not hold the sides of the transfer belt
unit. It may degrade print quality.
11 Align the arrows on the transfer belt unit with
the arrows on the machine.
12 Slide the transfer belt unit into the machine
and stop when the visible line reaches the
machine.
13 Lower the handles.
14 Push the front of the transfer belt unit to
reinstall it in the machine until it stops.
