4.3.1.3 Funkwerk Configuration Interface menus
The configuration options of your device are contained in the sub-menus, which are dis-
played in the navigation bar in the left-hand part of the window.
Note
Please note that not all devices have the full range of functions. Check the software of
your device on the corresponding product page under www.funkwerk-ec.com.
The Funkwerk Configuration Interface contains the following menus:
System Management
Menu Function
Status In this menu, general information on your device is displayed at
a glance.
This information includes serial number, software version, cur-
rent memory and processor use, status of the physical inter-
faces and the last 10 system messages.
Global Settings In this menu, you enter the basic system settings of your device,
such as, for example, system name, system date, system time
and passwords.
You can also manage licences that are necessary for the use of
certain functions.
Interface Mode / Bridge
Groups
In this menu, you define the mode in which the interfaces of
your device are to run (routing or bridging) and if necessary can
define bridge groups.
Administrative Access In this menu, you configure the access options for the individual
interfaces.
Remote Authentication In this menu, you configure the authentication via a RADIUS
server or TACAS+ server.
Physical Interfaces
Menu Function
Ethernet Ports In this menu, you configure the Ethernet interfaces of your
device. To do this, you select the speed and type of interface,
Funkwerk Enterprise Communications GmbH
4 Access and Configuration
funkwerk W1002/W2002/WIx040/WIx065 67
