FUTABA T10J - Elevon (Acrobatic)

101
Airplane
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe +
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
This mixing is used with delta wing, tailess, and disk shaped
airplanes that combine the aileron and elevator functions.
Connect the CH1 servo to the left aileron and the CH2 servo to the
right aileron.
ŏ7KHDLOHURQDQGHOHYDWRUWUDYHOFDQEHDGMXVWHGLQGLYLGXDOO\
NOTE：ElevoncannotbeusedsimultaneouslywithV-tailorAilevator
functions.YoumayuseFlaperonorDifferentialwhenthisfunctionisactive.
Ifanotherfunctionisalreadyactive,“OtherWINGmix“ON”isdisplayed
onthescreen.Aftersettingtheactivefunctionto“INH” ,settheelevon
functionto“ACT” .
"ELEVON"
ELEVON
Elevon
(ACROBATIC)
CH1servo CH2servo
Roll AIL1 AIL2
Pitch ELE2 ELE1
Activatingthefunction
Aileron1（CH1）rate
Aileron2（CH2）rate
Elevator2（CH1）rate
Elevator1（CH2）rate
● WhenINHisselected,the
functioncannotbeused.Touse
thefunction,selectACT.
（Aileronrate）
L：AileronstickLeftsiderate
R：AileronstickRightsiderate
（Elevatorrate）
● Selectthesettingitemwith
theJogkey.
■ Activatingthefunction
①Selectthe"MIX"itemandthen
selectthe"ACT"bypressing
the+keyor‒key.
＋ −
or
●Whenyoudonotuseafunction,
settothe"INH"side.
■ Rateset
＋ −
or
②Selectthe"RATE"itemandthenadjust
themixingratebypressingthe+keyor
‒key.
Range：-120 〜 +120%
Default：+100%
（onlyELE1:-100%）
● Whenyouwanttoreturnthesetvaluetotheinitialvalue,press
the+keyand‒keysimultaneously.However,polaritydoesnot
return.
NOTE：Werecommendthatsettingbeperformedwhilemovingthestickandcheckingtheamountofmovement.If
theamountofmovementistoolarge,elevatorandaileronoperationwillbecompoundedandtheservotravelrange
willbeexceededandadeadbandinwhichtheservowillnotoperatemaybecreated.
ELEVON
CH1
CH1
CH2
CH2
Pitch
Roll
(/(921
