97
Airplane
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe +
keyfor1second.
Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
(1second)
Callingthesettingscreen
"AIL-DIFF"
AIL-DIFF
Ailerondifferential
(ACROBATIC)
■Activatingthefunction
①Selectthe"MIX"itemandthen
selectthe"ACT"bypressing
the+keyor‒key.
or
Whenyoudonotusea
function,settothe"INH"
side.
Aileronrate
or
②Selectthe"RATE-AIL1"itemandmove
theaileronsticktotheleftandright
andadjustthetravelofeachservoby
pressingthe+keyor‒key.
Range:-120 +120%
Default:+100%
Whenyouwanttoreturntotheinitialvalue,pressthe+key
and‒keysimultaneously.However,whenthepolarityis
changedonlythenumberreturnstotheinitialvalue.
(Adjustthe"RATE-AIL2"iteminthesamewayas② .)
AileronDifferential
NOTE:AileronDifferentialcannotbeusedsimultaneouslywithFlaperonorElevon.If
anotherfunctionisalreadyactive,“OthersWINGmix“ON”isdisplayedonthescreen.After
settingtheactivefunctionto“INH” ,settheAileronDifferentialfunctionto“ACT” .
ACT/INH
Aileron1CH1rate
Aileron2CH7rate
WhenINHisselected,the
functioncannotbeused.Touse
thefunction,selectACT.
(Aileron)
L:AileronstickLeftsiderate
R:AileronstickRightsiderate
Selectthesettingitemwith
theJogkey.
CH1
CH7
The left and right aileron differential can be
adjusted independently. This function is restricted
to 2 servo aileron.
$,/',))
