FUTABA T10J - Aileron Differential (Glider); Aileron Control Surface Andle Adjustment

150
Glider
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe +
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
1AIL 2AIL 2AIL+1F 2AIL+2F 2AIL+4FWINGTYPE
Two servos can be used for ailerons and a
differential can be applied to left and right
aileron operation.
Connect the left aileron to CH1 (AIL) and the
right aileron to CH7.
ŏ7KHXSDQGGRZQDQJOHRIWKHOHIWDQGULJKWDLOHURQ
FRQWUROVXUIDFHFDQEHDGMXVWHGLQGLYLGXDOO\
"AIL-DIFF"
AIL-DIFF
Ailerondifferential
(GLIDER)
■ Aileroncontrolsurfaceangleadjustment
①Selectthe"RATE-AIL1"itemandthenmovetheaileronstick
totheleftandrightandadjustthetravelofeachbypressing
the+keyor‒key.
Range：-120 〜 +120%
Default：+100%
● Whenyouwanttoreturnthesetvaluetotheinitialvalue,press
the+keyand‒keysimultaneously.However,polaritydoesnot
return.
（AdjusttheRATE-AIL2itemthesameas② .）
AileronDifferential
Aileron1（CH1）rate
Aileron2（CH7）rate
（Aileronrate）
L：AileronStickLeftsiderate
R：AileronStickRightsiderate
● Selectthesettingitemwith
theJogkey.
CH1
CH7
$,/',))
