Commonfunction
Callingthesettingscreen
① UsetheJogkeytoselecttheP.MIX
numberyouwanttouse.
② Callthesettingscreenbypressing
theJogkey.
P.MIX1 4(normaltype)
P.MIX5 6(curvetype)
P.MIXSelection
(P.MIX1-6)
toP.MIX1 4
setupscreen
toP.MIX5 6
setupscreen
(P.MIX1 4setupscreen)
Mixingrateadjustment
Offset
MasterCHselection
SlaveCHselection
Functionactivation
WhenINHisselected,the
functioncannotbeused.
WhenON orOFFisselected,
thefunctionisactivated.ON
andOFFchangesarelinked
totheswitch.
TrimON/OFF
Switchselection
Switchdirection
Selecttheitemwiththe
Jogkey.
(MasterCHCurrentposition)
Functionactivation
① SelecttheMIXitemandselectON
orOFFbypressingthe+keyor‒
key.
or
Whenyoudonotwanttouse
thefunctionselectINH.
Master/slavechannelselection
② SelecttheMASTRchannelyouwant
tousebypressingthe+keyor‒key.
③ SelecttheSlavechannelyouwantto
usbypressingthe+keyor‒key.
AknobVRordigitaltrimDT5/DT6,aswellaschannels1
to10,canbespecifiedasthemasterchannel.Inaddition,
whenOFSwasselectedasthemasterchannel,slaveservo
operationisoffset.
Mixingrateadjustment
or
SelecttheRATEitemandadjustthe
mixingratebypressingthe+keyor‒
keyforeachdirectionofthestick,etc.
selectedatthemasterchannel.
Range:-100 +100%
Default:0%
Whenyouwanttoreturnthesetvalue
totheinitialvalue,pressthe+keyand‒
keysimultaneously.
(ChangingtheON/OFFSwitch)
ON/OFFSwitchselection
Selectthe"SW"itemandthen
selecttheswitchbypressingthe+
keyor‒key.
or
Selectionrange:SwA
SwH、THR
SwitchONdirectionsetting
Selectthe"POSI"itemandselecttheswitch
ONdirectionbypressingthe+keyor‒
key.
2PSW:NULL(alwaysON),UP,DOWN
3PSW:NULLalwaysON,UP,UP&D,UP&C,CNTR,C&DN,
DOWN
THRstick:HoldthestickattheON/OFFpoint
andsettheON/OFFpositionbypressingtheJog
keyfor1second.(IftheJogkeyispressedfor1
secondwhenthepositionwasset,itreturnsto
theNULLstate.)TheswitchONdirectioncanalso
beselectedbypressingthe+keyor‒key.
P.MIX1 4
or
or
(1second)
