FUTABA T10J - Various Telemetry Sensor (Optional) Information Display and Alarm Setting; Sensor Connection

74
Commonfunction
Various telemetry sensors (sold separately) are connectable to the S.BUS2 port of the R3008SB through
a 3-way hub and relay terminals. The information of sensors connected at initialization can be viewed as
long as 2 or more of the same kind of sensor are not used (for example, 2 temperature sensors).
● SensorsthatcanbeusedwiththeT10J:FutabaSBS-01T,SBS-01RM,SBS-01RO,SBS-01A,SBS-01V,SBS-01G
● RobbesensorsthatcanbeusedwiththeT10J:RobbeTEMP125,GPS-1675,VARIO-1712,VARIO-1672,CURR-1678
*FutabadoesnotsellRobbesensor.
Sensorinformationcanbeviewedbycallingtelemetryfromthemenuandcallingtheconnected
sensordisplaypage.Thedetailedsettingscreenofthatsensorcanbecalledbyselectingand
pressingthesensoryouwanttoselectwiththeJogkey.
● Refertothereceiverbattery(RX-BATT)itemforadescriptionofkeyoperation.
