FUTABA T10J - Activating the Throttle Curves (ID123); Curve Copying Method; Throttle Curve Setting Examples

135
Helicopter
● Throttlecurvesettingexamples
（Normal） （Idle-up1） （Idle-up2）
■ Curvecopyingmethod
①
Selectthe"CND"item
andswitchtothecurve
copymodebypressing
theJogkey.
②Pressthe+keyor‒
keyandselectthecopy
destinationcondition.
＋ −
or
③Copytheconditionby
pressingtheJogkeyfor
1second.
（1second）
■ Activatingthethrottlecurves(ID1/2/3)
＋ −
or
①
Selectthe"MIX"itemandsetto
"ON"or"OFF"bypressingthe+
keyor‒key.
● Forthenormalcondition,"---"isdisplayed.(AlwaysON)
● Whenyoudonotwanttouseanidleupcurve,setto
"INH".
Range：NOR,ID1,ID2,ID3
■ 5pointcurvesetting
②Selectthesettingitemofeachpoint(P-1 〜 P-5)
withtheJogkeyandsetthetravelofeachpointby
pressingthe+keyor‒key.
Range：0 〜 100%
Default：
P-5:100%
P-4:75%
P-3:50%
P-2:25%
P-1:0%
●
Whenyouwanttoreturnthesetvalueto
theinitialvalue,pressthe+keyand‒key
simultaneously.
Throttlecurve
0
100
50
25
75
P1 P2 P3 P4 P5
%
STICK
RATE
（Theexampleofasetting）
P5=100.0%
P4= 65.0%
P3= 50.0%
P2= 30.0%
P1= 0.0%
0
100
50
25
75
P1 P2 P3 P4 P5
%
P5=100.0%
P4= 75.0%
P3= 50.0%
P2= 54.0%
P1= 56.0%
STICK
RATE
（Theexampleofasetting）
0
100
50
25
75
P1 P2 P3 P4 P5
%
P5=100.0%
P4= 75.0%
P3= 65.0%
P2= 65.0%
P1= 67.0%
STICK
RATE
（Theexampleofasetting）
NOTE：Settheactualvalueofthethrottlecurveaccordingtothefuselage
specifications
.
＋ −
or
