FUTABA T10J - Activating the Pitch Curves (ID1;2;3, HLD); Pitch Curve Setting Examples

137
Helicopter
● Pitchcurvesettingexamples
（Normal）
（Hold）
（Idle-up1） （Idle-up2）
-100
+100
0
-50
+50
P1 P2 P3 P4 P5
%
P5= +70%
P4= +50%
P3= +6%
P2= -40%
P1= -70%
STICK
RATE
（Theexampleofasetting）
-100
+100
0
-50
+50
P1 P2 P3 P4 P5
%
P5= +100%
P4= +50%
P3= 0%
P2= -50%
P1= -100%
STICK
RATE
（Theexampleofasetting）
-100
+100
0
-50
+50
P1 P2 P3 P4 P5
%
P5= +40%
P4= +10%
P3= -10%
P2= -40%
P1= -70%
STICK
RATE
（Theexampleofasetting）
-100
+100
0
-50
+50
P1 P2 P3 P4 P5
%
P5= +40%
P4= +10%
P3= -10%
P2= -50%
P1= -80%
STICK
RATE
（Theexampleofasetting）
NOTE：Settheactualvalueofthepitchcurveaccordingto
thefuselagespecifications.
■ Activatingthepitchcurves（ID1/2/3,HLD）
＋ −
or
①
Selectthe"MIX"itemandthen
selectthe"ON"or"OFF"by
pressingthe+keyor‒key.
● Forthenormalcondition,"---"isdisplayed.(AlwaysON)
● Whenyoudonotwanttouseanidleup,holdcurve,set
to"INH".
Range：NOR,ID1,ID2,ID3,HLD
■ 5pointcurvesetting
②Selectthesettingitemofeachpoint(P-1 〜 P-5)
withtheJogkeyandsetthetravelofeachpointby
pressingthe+keyor‒key.
Range：-100 〜 +100%
Default：
P-5:+100%
P-4:+50%
P-3:0%
P-2:-50%
P-1:-100%
●
Whenyouwanttoreturnthesetvalueto
theinitialvalue,pressthe+keyand‒key
simultaneously.

Pitchcurve
■ Curvecopyingmethod
①
Selectthe"CND"item
andswitchtothecurve
copymodebypressing
theJogkey.
②Pressthe+keyor‒
keyandselectthecopy
destinationcondition.
＋ −
or
③Copytheconditionby
pressingtheJogkeyfor
1second.
（1second）
＋ −
or
