FUTABA T10J - Delay Rate Set; Switch Selection; Switch Direction; Operation Reference Point Setting (LINR Mode Only)

109
Airplane
■ Activatingthefunction
①
Selectthe"MIX"itemandthenselect
the"ON"or"OFF"bypressingthe+
keyor‒key.
＋ −
or
● Whenyoudonotuseafunction,set
tothe"INH"side.
■ Rateset
＋ −
or
②
Selectthe"rate"itemand
adjusttheservotravelby
pressingthe+keyor‒key.
Range：-100 〜 +100%
Default：+50%（ELEVonly-10%）
● Whenyouwanttoreturnthesetvaluetotheinitial
value,pressthe+keyand‒keysimultaneously.
However,polaritydoesnotreturn.
■ DelayRateset
＋ −
or
③Selectthe"delay"itemandadjusttheelevator
operationdelaybypressingthe+keyor‒key.
● Theamountofdelayislargeat100%.
Range：0 〜 100%、Default：0%
● Whenyouwanttoreturnthesetvaluetotheinitialvalue,pressthe+key
and‒keysimultaneously.
（Inthecaseofchangeofaswitch）
■ Switchselection
＋ −
or
①Selectthe"SW"
itemandthen
selecttheswitch
bypressingthe
+keyor‒key.
Range：SwA 〜 SwH
Default：SwC
■ Switchdirection
＋ −
or
②SelecttheONdirectionby
pressingthe+keyor‒keyat
theONdirectionselectionitem.
Range：
● 2PSW：NULL,UP,DOWN
● 3PSW：NULL,UP,UP&D,UP&C,CNTR,C&DN,DOWN
（Inthecaseofchangeofamode）
■ Mode
＋ −
or
①
Selectthe
"MOD"item
andselectthe
operationmode
bypressingthe+keyorthe‒key.
Range：OFST,LINR
Default：OFST
■ Operationreferencepointsetting("LINR"mode
only)
② Selecttheoperationreferencepointsetting
itemnewlydisplayedatthebottomrow
of"MOD"andholdthethrottlestickatthe
airbrakestartpointandsetthereferencepointby
pressingtheJogkeyfor1second.
Range：0 〜 100%
（When3CHcontrolischangedatthetimeof"LINR"）
■ "LINR"mode3CHcontrol
① Selectthe"CH3"itemandselectcontrolbypressingthe+keyor‒
key.
Range：THR,SwA 〜 SwH,VR,DT5,DT6
Default：THR
Airbrake
