FUTABA T10J - Ailvator (Acrobatic)

102
Airplane
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe +
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
Ailevator mixes both Ailerons and Elevators together. Or the
function can be used separate from your ailerons when you have two
(OHYDWRUVHUYRV6LQFHWKHUHDUHDLUFUDIWOLNHMHW¿JKWHUVWKDWXVHWKH
elevators as ailerons, using this function can give you a sense of reality.
$LOHURQRSHUDWLRQFDQDOVREHXVHGZLWKHOHYDWRUVHUYRVSHFL¿FDWLRQV
The servos connect to the receiver CH2 and CH8 output.
ŏ(OHYDWRUDQGDLOHURQWUDYHOFDQEHDGMXVWHGLQGLYLGXDOO\
ŏ&RQÀUPWKHGLUHFWLRQRIRSHUDWLRQEHFDXVHLWLVGLIIHUHQWGHSHQGLQJ
RQWKHOLQNDJH
"AILVATOR"
AILVATOR
Ailvator
(ACROBATIC)
CH2servo CH8servo
Roll AIL3 AIL4
Pitch ELE1 ELE2
● Selectthesettingitemwith
theJogkey.
Activatingthefunction
AIL3Rateset
AIL4Rateset
ELE2Rateset
ELE1Rateset
● WhenINHisselected,the
functioncannotbeused.Touse
thefunction,selectACT.
（Rate）
■ Activatingthefunction
①Selectthe"MIX"itemandthen
selectthe"ACT"bypressing
the+keyor‒key.
＋ −
or
● Whenyoudonotusea
function,settothe"INH"side.
■ Rateset
＋ −
or
②Selectthe"RATE"itemandthenadjust
themixingratebypressingthe+keyor
‒key.
Range：-100 〜 +100%
Default：-50%（AIL3,AIL4）,
-100%（ELE2）,+100%（ELE1）
● Whenyouwanttoreturnthesetvaluetotheinitialvalue,press
the+keyand‒keysimultaneously.However,polaritydoesnot
return.
NOTE：Werecommendthatsettingbeperformedwhilemovingthestickandcheckingtheamountofmovement.If
theamountofmovementistoolarge,elevatorandaileronoperationwillbecompoundedandtheservotravelrange
willbeexceededandadeadbandinwhichtheservowillnotoperatemaybecreated.
● Whenusedas2elevatorservosspecificationswithoutaileronoperation,settheAIL3andAIL4travelto0%.
AILVATOR
CH2
（CH8）
CH6
(CH7)
CH1
CH8
（CH2）
NOTE：AilevatorcannotbeusedsimultaneouslywithV-tailorElevonfunctions.When “OtherWINGmix“ON”“is
displayedonthescreen,settheailvatorfunctiontoACTaftersettingtheactivefunctiontoINH.
$,/9$725
