124
Helicopter
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe +
keyfor1second.
Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
(1second)
Callingthesettingscreen
This mixing is used to correct the bad tendencies
of the swash plate in the aileron direction and
elevator direction relative to aileron, elevator, and
pitch operations. It adjusts the rate of the direction
that requires correction so that the servo operates
smoothly in the proper direction relative to each
operation.
ŏ7KHFRUUHFWLRQDPRXQWRIHDFKFRQGLWLRQFDQEH
VHW
ŏ7KHOHIWDQGULJKWXS DQGGRZQFRUUHFWLRQ
DPRXQWFDQEHVHWIRUHDFKFRQGLWLRQ
"SWH.MIX"
Selectthesettingitem
withtheJogkey.
Condition
Mixingmasterdirection
Mixingrate
Activatingthefunction
(Presentcondition)
(Rate)
Whennotusingthisfunction,
selectINH.
Exampleofuse:Usingtocorrectbadrolltendencies
AIL ELEissettoON.
ACTION/ONiscommontoallconditions.Therateofunusedconditionsissetto0%.
Whenthenosedropsatrightrollandtherightsiderateisadjustedinthe"+"
direction,theelevatorsmovetotheupsidewhentherightaileronisdeflected.
Leftrollcanbeadjustedbyleftsiderate.
However,sincetheleft andrightaileronspolarityand elevatorsoperatingdirection
relationshipisreversed;checkthecorrectiondirectionbyswashplateoperation.
SWH.MIX
Swashmixing
(HELICOPTER)
