FUTABA T10J - Throttle-Needlemixing (for Helicopters)

147
Helicopter
Function
8CH
This mixing sets the mixture by a 5 point curve in relation to throttle
stick movement when the engine is equipped with a mixture control
system (needle control or other mixture adjustment). Normal condition
(NOR) idle up use (ID2) and idle up 3 (ID3) can be set independently.
The needle servo connects to CH8 of the transmitter.
Method
①Callthemenuscreenfromthe
homescreenbypressingthe +
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
"THR → NEEDL"
THR
→
NEEDL
Throttle → Needlemixing（
Forhelicopters
）
(HELICOPTER)
Activatingthefunction
Condition
5pointcurve
set
● Selectthesettingitem
withtheJogkey.
● Whennotusingthisfunction,
selectINH.
（Presentcondition）
● TheCURVEsettingsare
displayedbyacurve.
■ Activatingthefunction
＋ −
or
①
Selectthe"MIX"itemandthen
selectthe"ON"or"OFF"by
pressingthe+keyor‒key.
● Whenyoudonotuseafunction,settothe"INH"side.
●Whensuch,settingconditioncanbe
chosenbypressingJogkey.
Range：NOR,I12,ID3
■ 5pointcurveset
＋ −
or
ting
②Selectthesettingitemofeach
point(P-1 〜 P-5)withtheJog
keyandsetthetravelofeach
pointbypressingthe+keyor‒
key.
Range：0.0 〜 100.0%
Default：
P-5:100.0%
P-4:75.0%
P-3:50.0%
P-2:25.0%
P-1:0.0%
● Whenyouwanttoreturnthesetvalue
totheinitialvalue,pressthe+key
and‒keysimultaneously.
Throttle → Needlemixing
■ Curvecopyingmethod
①
Selectthe"CND"itemand
switchtothecurvecopy
modebypressingtheJog
key.
②Pressthe+keyor‒keyand
selectthecopydestination
condition.
＋ −
or
③Copytheconditionby
pressingthe Jogkeyfor1
second.
（1second）
