55
Commonfunction
(Changingthemixingreferencepoint)
(Includingtrimoperation)
Mixingreferencepointsetting
(1second)
① Selectthe"OFFST"itemandhold
themastersidestickorknobin
thepositionyouwanttosetand
setthenewreferencepointby
pressingtheJogkey.
Range:-100 +100%
THRonly0 100%
Default:0%
TrimON/OFFsetting
or
Selectthe"TRM"item
andselectONorOFFby
pressingthe+keyor‒key.
Range:OFF、ON
Default:OFF
Whenyoudonotwanttoincludetrimin
mixingselectOFF.

At the end of setting, check that the mixing function is performed normally.
(P.MIX5 6setupscreen)
Selecttheitemwiththe
Jogkey.
5Pointcurve
setting
Thesetcurveisdisplayedona
graph.
Functionactivation
MasterCHselect
SlaveCHselect
Switchselection
SwitchONdirection
WhenINHisselected,the
functioncannotbeused.
WhenON orOFFisselected,
thefunctionisactivated.ON
andOFFchangesarelinked
totheswitch.
RefertotheP.MIX1 4settingmethoddescribedpreviouslyforsettingsotherthanthe5pointcurvesetting
describedbelow.
5pointcurvesetting
or
① Selectthesettingitem(P-1 P-5)ofeachpointwiththeJogkeyandsettheamountof
movementofeachpointbypressingthe+keyor‒key.
Range:-100 +100%
Default:0%

At the end of setting, check that the mixing function is performed normally.
P.MIX5 6
CAUTION
CAUTION
