117
Airplane
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe +
keyfor1second.
Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
(1second)
Callingthesettingscreen
However,thisfunctioncannotbeusedwhenthethrottleEXPfunctionwasset.Whenthisfunctionisset,
thethrottleEXPfunctioncannotbeused.
This function sets a 5 point throttle curve so that
the engine/motor speed relative to movement of the
WKURWWOHVWLFNLVWKHRSWLPXPYDOXHIRUÀLJKW
ŏ$FXUYHFDQEHVHWIRUHDFKVZLWFKSRVLWLRQ
"THR-CURVE"
THR-CURVE
Throttlecurve(Airplane)
(ACROBATIC)
Activatingthefunction
or
Selectthe"MIX"item
andthenselectthe
"ON"bypressingthe+
keyor‒key.
Whenyoudonotuseafunction,settothe
"INH"side.
Switchselection
or
Selectthe"SW"item
andthenselectthe
switchbypressingthe
+keyor‒key.
Range:SwA SwH、Default:SwE
5pointcurveset
or
③ByJogkey,eitherofP-1toP-5ischosen.The+keyor-keyispressedanda
rateissetup.
Range:0 100%
Default:P-1:0%,P-2:25%,P-3:50%,P-4:75%,P-5:100%
Throttlecurve
Activatingthefunction
Switchselection
5pointcurve
set
Selectthesettingitem
withtheJogkey.
Whennotusingthisfunction,
selectINH.
Theset-upcurveisshown
(Presentswitchposition)
7+5&859(
