FUTABA T10J - Program Mixing 16; P.MIX 14 (Normal Type); P.MIX 56 (Curve Type)

53
Commonfunction
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe+key
for1second.
＋
② Select
fromthemenuwiththeJog
key.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
P.MIX1 〜 4(normaltype)
Thefollowingfunctionscanbesetforprogrammablemixing1to4:
【MixingChannel】
● Usethisfunctionbychangingthechannelbecausethemasterchannelandslavechannelsinitialsettingisa
temporarycombination.
● WhenOFSwasselectedasthemasterchannel,themixingratesettingappliestoslaveonly.Whenamixing
rateisset,slaveservooperationisoffsetbythatamount.
● Aknob(VR)ordigitaltrim(DT5,DT6),aswellasachannel,canbeselectedasthemasterchannel.
【Trimselection】
● Whetherornotmixingincludesmasterchanneltrimoperationcanbeselected.
【Mixingreferencepointchange】
● Themasterchannelmixingreferencepointcanbeshifted.
【Switchselection】
● TheprogrammablemixingON/OFFswitchcanbeselected.TheswitchesthatcanbeselectedareswitchesAto
Handthethrottlestick.
● Theswitchoperatingdirectioncanbeset.Whena2positionswitchwasselected,up/downcanbeset,and
whena3positionswitchwasselected,up/upanddown/up/andcenter/center/centeranddown/downcan
beselected.Whenthethrottlestickwasselected,theON/OFFpositionandoperationdirectioncanbeset.
When"NULL"isselected,mixingisalwaysON.
P.MIX5 〜 6（curvetype）
Programmablemix5to6allowssettingofthemixingrateby5pointcurve.
OFSandknob/digitaltrimuseandtrimselectionbynormaltypemasterchannelsettingdescribed
aboveareimpossible,butswitchselectionispossible.
Mixing that can independently customize 6
functions can be used. Programmable mixing is
used to remove bad tendencies of the aircraft and
PDNHRSHUDWLRQSOHDVDQW,QDGGLWLRQWRPL[LQJ
between arbitrary channels, this function includes
linking (linking with another mix), trim addition,
offset, and switch setting functions.
"P.MIX1-6"
P.MIX1-6
Programmixing1 〜 6
(Common)
