EST3 Installation and Service Manual 8.25
Table 8-18: System pseudo points
Address Label Source Functional description
0014 Reset Phase 3 CPU Changes to the active state when the
third phase of the 3-phase reset cycle
starts.
0015 First Disable Response CPU Changes to the active state when the firs
t
point on a panel or any panel in the same
network routing group changes to the
disable state.
0016 Fail Safe Event CPU Changes to the active state when a
device asserts the rail alarm-not line and
the CPU module has not registered an
alarm event.
0017 Service Group Active CPU Changes to the active state when an
operator enables a Service Group from
the LCD module.
0018 Two Stage Timer Active CPU Changes to the active state when a
panel’s two-stage alarm timer starts.
0019 Loop Controller Reset
Extension
CPU Changes to the active state when a loop
controller stays in the reset mode longer
than expected.
0020 Service Device Supervision CPU Changes to the active state when an
operator cancels a Service Group test
while a circuit under test remained active.
0021 User Trouble CPU Changes to the active state when an
operator forces a trouble into the system.
Not implemented at this time.
0022 Ext Database Incompatibility CPU Changes to the active state when a
different database in one or more
network nodes
0023 Reboot Fault CPU Changes to the active state when the
CPU module is interrupted unexpectedly.
0101–
0164
Comm Fail xx CPU Changes to the active state when the
CPU is unable communicate with the
networked CPU module in cabinet xx.
0200–
0222
Task xx Watchdog Violation CPU Changes to the active state when task xx
fails to execute properly.
0261–
0279
Configuration Mismatch Card
xx.
CPU Changes to the active state when the
card in slot xx can not perform the
programmed advance feature (currently
only degraded mode).
0281–
0299
DB Out Of Sync with CPU
Card xx
CPU Changes to the active state when the
Signature controller module in rail slot xx
reports an actual and expected data
mismatch.
