8.26 EST3 Installation and Service Manual
Table 8-19: Local alarm pseudo points
Address Label Source Description
0676 Unprogrammed Device 3-AADC1 Device not defined in SDU database is in
alarm or trouble state
0676 Unprogrammed Device Data
Card 1
3-DSDC
3-SSDC1
3-SDDC1
Device not defined in SDU database is in
alarm or trouble state
0686 Unprogrammed Device Data
Card 2
3-DSDC
3-SSDC1
3-SDDC1
Device not defined in SDU database is in
alarm or trouble state
Table 8-20: Local trouble pseudo points
Address Label Source Description
0001 Class A Fault Spur 3-SAC Fault or break in Class A loop on SAC
bus
0002 Class A Fault Video Bus 3-SAC Fault or break in Class A loop on
video bus
0003 Annunciator Supervision 3-SAC Control / display module faulty or
missing or not properly configured
0004 Rail Module Communication
Fault
3-SAC Cabinet local rail communication
failure
0005 Video Communication Fault 3-SAC Fault or break in video signal lines
0006 RAM Fault or Stack Fault 3-SAC Fault in internal 3-SAC processor
0007 Code Supervision 3-SAC Executable program corrupt
0008 Internal Fault 3-SAC 3-SAC hardware failure
0009 Configuration Fault 3-SAC 1. Module in wrong slot
2. Incorrect display on module
0010 Database Supervision 3-SAC Database corrupt
0071 Task Failure 3-SAC
0071 Waiting for SDU Download 3-SAC Database download from the SDU is
in progress or was incomplete
0600 Annunciator Supervision General Control / display module faulty or
missing or not properly configured
0601 Class A Failure CPU Fault or break in Class A network
data riser connection
0601 Rail Module Communication
Fault
General Cabinet local rail communication
failure
0602 Ground Fault Detection CPU Any cabinet component or field wiring
0603 Audio Supervision CPU Audio data circuit open or shorted
