GE Security EST3 User Manual

Service and troubleshooting
8.30 EST3 Installation and Service Manual
Table 8-20: Local trouble pseudo points
Address Label Source Description
0655 RAM Diagnostic Failure 3-ASU Memory failure in 3-ASU
0656 Audio Default Failure 3-ASU 1. 3-ASUMX memory card missing
2. Audio database does not exist
0658 Audio Interface Failure 3-ASU 3-ASU hardware fault
0659 Audio Class Supervision 3-ASU One riser open or shorted
0670 In Bootloader 3-AADC1 PC connected to card attempting
download
0670 In Bootloader 3-DSDC
3-SSDC1
3-SDDC1
PC connected to card attempting
download
0671 Line Opened or Shorted 3-AADC1 Wiring Fault
0671 Line Opened or Shorted Data
Card 1
3-DSDC
3-SSDC1
3-SDDC1
Wiring Fault
0672 Map Fault Data Card 1 3-DSDC
3-SSDC1
3-SDDC1
1. Mismatch between actual data and
expected data
2. Defective wiring
3. Defective device
0677 Grnd Fault 3-AADC1 Wiring Fault
0677 Grnd Fault Data Card 1 3-DSDC
3-SSDC1
3-SDDC1
Wiring Fault
0678 Reconstct Line 3-AADC1 N/A
0679 Smoke Power Current Limit 3-AADC1 N/A
0679 Smoke Power Current Limit
Card 1
3-DSDC
3-SSDC1
3-SDDC1
N/A
0680 Internal Failure 3-LDSM N/A
0681 Line Opened or Shorted Data
Card 2
3-DSDC
3-SSDC1
3-SDDC1
Wiring Fault
0682 Map Fault Data Card 2 3-DSDC
3-SSDC1
3-SDDC1
1. Mismatch between actual data and
expected data
2. Defective wiring
3. Defective device
0687 Grnd Fault Data Card 2 3-DSDC
3-SSDC1
3-SDDC1
Wiring Fault
