8.34 EST3 Installation and Service Manual
Table 8-25: Local relay pseudo points
Address Label Source Description
0002 Amplifier Backup 3-ZAxx Changes to the active state when the
amplifier’s input relay selects the back up
amplifier input as its signal source.
0003 Channel_1_Relay_
Confirmation
3-ZAxx Changes to the active state when the
amplifier’s input relay selects channel 1.
0004 Channel_2_Relay_
Confirmation
3-ZAxx Changes to the active state when the
amplifier’s input relay selects channel 2.
0005 Channel_3_Relay_
Confirmation
3-ZAxx Changes to the active state when the
amplifier’s input relay selects channel 3.
0006 Channel_4_Relay_
Confirmation
3-ZAxx Changes to the active state when the
amplifier’s input relay selects channel 4.
0007 Channel_5_Relay_
Confirmation
3-ZAxx Changes to the active state when the
amplifier’s input relay selects channel 5.
0008 Channel_6_Relay_
Confirmation
3-ZAxx Changes to the active state when the
amplifier’s input relay selects channel 6.
0009 Channel_7_Relay_
Confirmation
3-ZAxx Changes to the active state when the
amplifier’s input relay selects channel 7.
0010 Channel_8_Relay_
Confirmation
3-ZAxx Changes to the active state when the
amplifier’s input relay selects channel 8.
0011 Page Select 3-ZAxx Changes to the active state when the
amplifier’s input relay selects the Page
channel.
