Service and troubleshooting
EST3 Installation and Service Manual 8.59
Table 8-36: Signature controller module Internal Messages
Query Trouble Status Find New PreAlarm Enable Visible LED
Query New Start Status Find New Normal Disable Visible LED
Query Active Status Find New Trouble Enable External Output
Disable External Output Assign All Address 3-SDC Processor Status Query
Open Line Isolator Relay Control 3-SDC Enable Loop
Close Line Isolator Read Software
Version 3-SDC Disable Loop
Reset Device Status Read Device Status 3-SDC Line Initialization
Complete
Move EEPROM to RAM Read Sensor Values 3-SDC Send a Device Msg.
Assign Short Address Read Specific Trouble 3-SDC Get a Device Reply
Assign Group Address Read Value From RAM 3-SDC Configure Loop
Enter Service Mode Send Value to Visible LED 3-SDC Query Current
Configuration
Select Sensors Query New Status 3-SDC Send Signal Rate
Write Value to RAM 3-SDC Command Initiate
Reset
3-SDC Query Signal Status
Write Value to EEPROM 3-SDC Command Initiate
Restart
Displaying device trouble
Each Signature device is equipped with a 32-bit trouble register.
Should a device’s trouble bit be set at any time in the device’s
history, the device and the nature of the trouble will appear in the
Latching Troubles By Device Address window. Clicking on the
device will reveal a list of the trouble conditions affecting that
device. Click the device a second time to remove the trouble
listing.
