Revision C 250cx Series Maternal/Fetal Monitor 11-13
2036946-001
Recorder Modes: Adjustable Recorder Font Size
Adjustable Recorder Font Size
The 250cx Series Monitor offers a choice of font sizes to print annotations. (Refer to
Table , “Summary of Annotations,” on page 11-10.) A larger font size fosters
readability; a smaller font size increases printing speed.
Set the font size on the password-protected Install Options service screen. Refer to the
“250/250cx Series Monitor Service Manual” for more information.
CAUTION
FONT SIZE—If the medium or large font size is selected, there is
the possibility that messages may be truncated during periods of
multiple annotations.
This annotation prints on the bottom two lines of the upper grid indicating that the
mother perceives fetal movement. The arrow prints each time the mother
presses the FM Remote Marker button.
Note: A horizontal bar prints as a tail on the arrow for as long as the button is
held down.
(The Remote Marker is an accessory that can be connected to the 250cx Series
Monitor. The monitor can be configured to use this annotation or the one shown
in the previous row of this table. Refer to the “250/250cx Series Monitor
Service Manual”.)
This annotation prints on the bottom two lines of the upper grid indicating that the
Corometrics Model 146 Fetal Acoustic Stimulator is being used. The music
symbol prints each time a clinician presses the button on the stimulator.
Freestyle annotations. For example:
PT. NAME: JANET STEVENS
PT. ID#: 6535148
PT. AGE: 18 DR. CARTER
Entries typed using a Corometrics Model 2116B Data-Entry/Clinical Notes
Keyboard print in the annotation area. (The Model 2116B is an optional device
that can be connected to the 250cx Series Monitor.)
Summary of Annotations (Continued)
Annotation Explanation
