Maternal Heart/Pulse Rate Monitoring: MHR/P Setup Screen
MHR/P Setup Screen
Select the mode title softkey—MECG or Pulse—to access the MHR/P Setup screen.
(Refer to the following figure.)
NOTES
The figure below provides an example of MECG selected as the MHR/P
source, as indicated by the MECG mode title. When either MSpO
2
or NIBP
are selected as the MHR/P source, the mode title changes to Pulse.
The Lead source and Pacer fields apply to MECG only.
MHR/P Setup Screen
Source
This field selects the MHR/P source. When Auto is selected, the monitor checks for
parameter availability and use in the following order: MECG, MSpO
2
, then NIBP. If
a source is not available, the next available source is automatically selected.
IMPORTANT
WAVEFORM—The MHR/P Source field is independent of the
waveform selected on the normal operating screen. For example,
you can select MECG as the MHR/P source yet display the
MSpO
2
plethysmograph waveform. Or, you can select MSpO
2
as
the source and display MECG as the waveform.
Alarms High Low
MHR/P: 120 50 bpm
Alarm Volume 5
165
172
30
US
FECG
TOCO
MHR/P Setup
89
MECG
Source:
HR/PR Trace:
Volume: 5
MECG
Lead: II
Pacer: Off
35-120
On
Off
I, II, III
On
Off
Auto
MECG
MSpO
2
0
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Auto
Off
Exit
100-250
To Next Page
