Alarms: Alarm Setup
Alarm Setting Indicators
An alarm setting indicator displays for FHR1, FHR2, NIBP, MHR/P, and MSpO
2
.
The following table provides a summary of the two possible states for this indicator
NOTE: The FHR alarms may be completely disabled from the password-protected
Install Options service screen. When disabled, the alarm setting indicator is
not displayed.
.
Maternal Alarm Occurring During Setup
Alarm Behavior
If the visual indication of a maternal alarm is inhibited by a setup screen, only an
audio alarm (if enabled) is issued. As soon as you exit the setup screen, the visual
alarm indication displays.
Example: If the NIBP Setup screen is displayed, the primary labor parameters
continue to be displayed as well as the maternal NIBP area of the screen. Under
an alarm condition that affects NIBP, both a visual and audible alarm is issued.
Under an alarm condition that affects MSpO
2
or MECG, only an audio alarm (if
enabled) is issued while the NIBP Setup screen remains displayed. Once the
setup screen is exited, the visual alarm indication for MSpO
2
or MECG
displays.
Alarm Setting Indicators
Mode
All of the following are true: At least one of the following is true:
FHR
The FHR audio alarm is on.
Each of the FHR high/low limits is set to a value.
The FHR audio alarm is off.
The FHR high limit is off.
The FHR low limit is off.
NIBP
The NIBP audio alarm is on.
Each of the NIBP high/low limits is set to a value.
Maternal alarms cannot be turned off.
MHR/P
The MHR/P audio alarm is on.
Each of the MHR/P high/low limits is set to a value.
Maternal alarms cannot be turned off.
MSpO
2
The MSpO
2
audio alarm is on.
Each of the MSpO
2
high/low limits is set to a value.
Maternal alarms cannot be turned off.
