Revision C 250cx Series Maternal/Fetal Monitor C-13
2036946-001
Spectra Alerts: Trend Screen
Trend Screen
Select the Trend softkey from the FHR Setup screen to display the FHR/UA trend
screen. (For dual fetal heart rate monitoring, you can access it from either mode’s
setup screen.) The Trend screen displays:
the alert level and message, if present;
the most recent 10 minutes of FHR and UA trend data—reflecting the paper
scale and chart speed settings; and
the current time.
The following Figure shows a sample Trend screen with dual FHR monitoring in
progress and a level one decelerations alert.
Trend Screen Example
Uterine Contraction Frequency
The Spectra Alerts option includes a uterine contraction (UC) frequency display.
When enabled, the UA screen:
provides the setup field for the UA display;
provides a uterine contraction audio indicator; and
provides a UC frequency histogram which graphs the contractions per 10
minutes over the most recent 100 minutes.
30
210
1
Exit
US
FECG
TOCO
210
160
120
50
100
50
0
10:56:41
*
Decelerations?
*
Alert level and message.
The Trend screen displays the most recent 10
minutes of FHR and uterine activity data.
For dual heart rate monitoring, the same trend
screen displays regardless of which FHR setup
screen (FECG or US/US2) you use to access
the Trend screen.
The current time.
