4-8 250cx Series Maternal/Fetal Monitor Revision C
2036946-001
Setup Procedures: Setup Screens
Using the Trim Knob Control
General instructions for using the Trim Knob control follow:
NOTE: When any setup screen (except
the General Setup screen) is displayed,
the primary labor parameters remain
displayed.
1. To display a parameter setup screen, rotate the Trim Knob control until the bar
cursor highlights the title of the parameter (FECG, US, US2, NIBP, MECG, Pulse, or
MSpO
2
). To access the Master Alarm Setup screen or the General Setup screen,
rotate the Trim Knob control until the bar cursor highlights the Alarms softkey or
the Setup softkey, respectively, on the bottom of the screen.
2. Press the Trim Knob control once to display the selected setup screen.
3. While the screen is displayed, rotate the Trim Knob control until the desired
field is highlighted.
4. Press the Trim Knob control again to activate the selected field. The cursor
flashes to indicate the field is active.
5. Rotate the Trim Knob control in either direction to cycle through the available
choices for the field.
6. When the desired selection is made for the field, press the Trim Knob control
once to confirm the selection.
7. Repeat Steps 3 through 6 until all desired settings have been made.
8. Rotate the Trim Knob control until the bar cursor highlights the Exit softkey on
the bottom of the screen. This returns the monitor to normal operation.
IMPORTANT
EFFECTIVITY—All changes take effect immediately after a selection is
enacted in Step 6. Some changes take effect as the values are changed
without having to press the Trim Knob.
