B-4 250cx Series Maternal/Fetal Monitor Revision C
2036946-001
Fetal Movement Detection: Using Fetal Movement Detection While Monitoring
Display Indicator
When fetal movement detection is enabled, and a transducer is plugged in, the
annotation FMD appears in-between the FHR1 and FHR2 mode titles. (Refer to
Figure below.)
US Setup Screen
Strip Chart Annotation
When fetal movement detection is enabled, the mode annotation FMD prints
following the FHR modes. The annotation provides an indication that the feature is
enabled—it does not indicate detection.
When fetal movement is detected, a solid line is automatically marked on the bottom
of the upper grid for the duration of the detected movement. (Refer to Figure,
“Simulated Fetal Movement Detection Trace,” on page B-5.)
Using the FM Remote Marker to Complement the Patient Record
The FM Remote Marker is an accessory that can be used to complement the patient
record.
1. Connect the Corometrics FM Remote Marker to the Remote Marker
connector on the rear panel of the 250cx Series Monitor.
2. Instruct the mother to press the FM Remote Marker button whenever she feels
fetal movement. Ask her to hold down the button for the duration of the
perceived fetal movement. The annotation, or , with a horizontal bar,
prints on the strip chart for as long as the button is held down. (Refer to Figure,
“Simulated Fetal Movement Detection Trace,” on page B-5.)
165
30
Exit
US
TOCO
Volume:
US Setup
FMD
5
Volume:
5
FM Detect: On
