2018112-069 Rev. F eBike II, eBike II L, eBike II EL - 113 -
eBIke II el
preventIve MaIntenanCe
fInal CHeCkout proCedure / funCtIonal test
• Visually inspect the device
- Inspect coat of lacquer
- Inspect cables/power cord
- Inspect bellows on steering column and saddle
- Inspect footboard for stability
- Inspect cu, tubing and tubing connection
- Inspect couch adjustment motors for damage
- Check the setup for stability, lock castor brakes, if required.
- Inspect outrigger.
Expected result: No damage, instability or wear detected Pass/Fail
• Check rests, cranks, pedals and Velcro strips
- Check that all clamping levers and star grips are rmly seated
- Check that cranks, pedals, Velcro strips and pedal shoes are properly xed.
- Fold down drop section
- Inspect leg rests and their attachment, if leg rests are installed.
- Inspect head and arm rests as well as handgrips.
- Grease the threads of the clamping levers (every 6 months, depending on application purpose).
(Use of an universal high-performance lubricant such as OKS 470 is recommended)
Expected result: All threads properly greased, cranks, rests and pedals OK Pass/Fail
• Power on
- Using the power cord, connect the device to the power line and
turn it on with the power switch.
- Wait for self-test to end:
Check LCD, e.g. for error messages.
- Check in the software if the rmware version is OK.
Expected result: Device powers on without errors and FW is OK Pass/Fail
• Both couch adjustment motor
- Set both motors to both stop positions
- Change couch position from horizontal (0°) to semi-recumbent (45°)
and then back to thehorizontal position (0°)
- Check adjustment range for lateral tilt from the horizontal position (0°)
Expected result: Couch position changes to the expected positions Pass/Fail
Hint
• eBike II EL is a protection class I device (with connection to protective ground)
• Suitable common ground terminal:
screw head of the protective earth connection
• preventive maintenance has to be performed every 2 years
